Bentley SIG Workshop: Geotechnical Analysis – Embankment Modelling and Auto-generated 2D Sections

With a long road embankment, multiple cross-sections in the 2D model must typically be created to evaluate stability and settlements for the whole road embankment. This can be time-consuming and may take much effort as each cross-section is generated manually.

Register to 10 A.M. CET SIG Workshop

Register to 4 P.M CET SIG Workshop

Use of Python scripting can be helpful when generating cross-sections and provide all necessary results for evaluation. During this Geotechnical Analysis Special Interest Group virtual workshop, we will look at how the Python script is developed and
how it can be used with PLAXIS 2D CONNECT Edition. You will learn how to:

• Build up an embankment model
• Run a Python script to assist in creating 2D embankment sections
• Apply and understand the possibilities of this automated procedure
• Adjust the procedure to best meet your needs

The Geotechnical Analysis SIG is open to all Bentley users, so feel welcome to invite your colleagues. One learning unit is applied to each attendee’s Bentley Transcript for self-reporting.
